JEE Main · 2024 · 05 Apr 2024 · Shift 1 · Geometrical Optics

Consider an equilateral prism (refractive index $\sqrt{2}$ ). A ray of light is incident on its one surface at a certain angle $i$. If the emergent ray is found to graze along the other surface then the angle of refraction at the incident surface is close to ____ .

A parallel beam of light travelling in air (refractive index 1.0) is incident on a convex spherical glass surface of radius of curvature 50 cm . Refractive index of glass is 1.5 . The rays converge to a point at a distance x cm from the centre of the curvature of the spherical su …

In parallax method for the determination of focal length of a concave mirror, the object should always be placed :

The wavelength of light, while it is passing through water is 540 nm. The refractive index of water is $\frac{4}{3}$. The wavelength of the same light when it is passing through a transparent medium having refractive index of $\frac{3}{2}$ is $\_\_\_\_$ nm.

As shown in the diagram, when the incident ray is parallel to base of the prism, the emergent ray grazes along the second surface.

If refractive index of the material of prism is $\sqrt{2}$, the angle $\theta$ of prism is.

A thin prism with angle $5^{\circ }$ of refractive index 1.72 is combined with another prism of refractive index 1.9 to produce dispersion without deviation. The angle of second prism is ______.
